Environmental pollution control for many manufacturers large and small has become increasingly important. There are over 45 states in the U.S. that offer incentives for implementing pollution control equipment. This combined with the benefits of reducing health hazards, equipment damage, and increasing workplace safety, it is easy to see why this industry has taken the forefront in pollution control. WII`s line of dust collection accessories is your one stop shop for all of your dust collection accessory needs. We offer Goyen`s leading diaphragm valves, solenoid valves, and enclosures; instrumentation control panels, cast venturis, and replacement filter caps. Give us a call at (609) 208-1428 or scroll down the following pages to see how WII can help you.
Goyen manufactures diaphragm valves in a range of configurations to suit a variety of reverse pulse filter designs. These sophisticated valves precisely control airflow through the filters for optimal cleaning. The range now includes the exciting "next generation" Millennium series which sets a new standard in performance, design, ease of installation and maintenance economy. The range of Diaphragm valves includes: 3 Series Pulse Jet Valves T Series Pulse Jet Valves DD Series Pulse Jet Valves FS Series Pulse Jet Valves MM Series Pulse Jet Valves
Goyen manufactures diaphragm valves in a range of configurations to suit a variety of reverse pulse filter designs. These sophisticated valves precisely control airflow through the filters for optimal cleaning. The range now includes the exciting "next generation" Millennium series which sets a new standard in performance, design, ease of installation and maintenance economy. The range of Diaphragm valves includes:
Description:Superior performance, easy maintenance diaphragm valve available with threaded ports (T3 Series), dresser nut ports (DD3 Series) or flange and slide ports (FS3 Series). Outlet at 90 degrees to inlet. 3 Series valves are available as remote pilot valves and may be converted to integral pilot applications through the use of the screw in pilots of the MIP and 3DS series. All 3 Series valves are supplied with CASTEC protection, offering 500 hours resistance to salt spray. Dust collector applications, in particular for reverse pulse jet filter cleaning and its variations including bag filters, cartridge filters, envelope filters, ceramic filters, and sintered metal fiber filters.
Pipe/Orifice Size
Valve Model
Cv
Kv
Diaphragm Repair Kits
DESCRIPTION Goyen "T" series valve has a right angle body, the 90 degree angle between inlet and outlet being considered a most suitable configuration for dust collector applications. The design offers ease of installation, low restriction of air flow and an excellent cleaning pulse. The valve has female "threaded" ports on the inlet and outlet that facilitates secure installation to the header-manifold-tank threaded stub pipe. The valves can be operated by either integral pilot solenoids (CA Models) or remote pilot solenoids (RCA Models). The "T" series valves are available in 7 sizes ranging from 3/4 (20mm) up to 3 (76mm) in NPT, RC and G thread types. CONSTRUCTION Body and cover are pressure die cast aluminum. General purpose diaphragms are made from Buna N elastomer, reinforced with nylon mesh, and are suitable for temperatures ranging from -40C (-40F) up to 82C (180F). High temperature diaphragms are made from Viton and are suitable for temperatures up to 232C (450F). All seals are designed to meet the same operating criteria. FEATURES Seven sizes to suit a variety of applications.
DESCRIPTION
Goyen "T" series valve has a right angle body, the 90 degree angle between inlet and outlet being considered a most suitable configuration for dust collector applications. The design offers ease of installation, low restriction of air flow and an excellent cleaning pulse. The valve has female "threaded" ports on the inlet and outlet that facilitates secure installation to the header-manifold-tank threaded stub pipe. The valves can be operated by either integral pilot solenoids (CA Models) or remote pilot solenoids (RCA Models). The "T" series valves are available in 7 sizes ranging from 3/4 (20mm) up to 3 (76mm) in NPT, RC and G thread types.
CONSTRUCTION
Body and cover are pressure die cast aluminum. General purpose diaphragms are made from Buna N elastomer, reinforced with nylon mesh, and are suitable for temperatures ranging from -40C (-40F) up to 82C (180F). High temperature diaphragms are made from Viton and are suitable for temperatures up to 232C (450F). All seals are designed to meet the same operating criteria.
Description The "FS" Series has a revolutionary design with it`s "F" flanged inlet and the "S"slide outlet. The "FS" Series valve bodies and covers are manufactured from glass filled nylon. Designed to be mounted directly into the compressed air manifold. All models are available in pressure die-cast aluminum or stainless steel bodies and covers. General purpose diaphragms are made of Buna-N reinforced with nylon mesh. Applications of high temperature need Viton kits. Construction: Body: Diecast Aluminum or 316 SS Ferrule: 304 SS Armature: 430FR SS Seals: Nitrile or Viton Spring: 304 SS Screws: 302 SS Outlet Slide Seal: EPDM or Viton Diaphragm Seat: PA-6, Viton Coated Mild Steel
Description
The "FS" Series has a revolutionary design with it`s "F" flanged inlet and the "S"slide outlet. The "FS" Series valve bodies and covers are manufactured from glass filled nylon. Designed to be mounted directly into the compressed air manifold. All models are available in pressure die-cast aluminum or stainless steel bodies and covers. General purpose diaphragms are made of Buna-N reinforced with nylon mesh. Applications of high temperature need Viton kits.
Construction:
Body: Diecast Aluminum or 316 SS
Ferrule: 304 SS
Armature: 430FR SS
Seals: Nitrile or Viton
Spring: 304 SS
Screws: 302 SS
Outlet Slide Seal: EPDM or Viton
Diaphragm Seat: PA-6, Viton Coated Mild Steel
